Shaped Stainless Steel Ice Pop Mold

Hongtai is a professional manufacturer of ice cream making molds used in all kinds of machinery. We have developed more than 1200 different mold types of various shapes and sizes. Below you will see a shaped stainless steel ice pop mold and its dimensions. If you require products with specifications that are not listed among our mold cups, we can also provide custom services upon request.

  • MOD8028 Ice Pop Mold
    CAPACITY MAX =108ml
    FILL LINE 6mm =100ml
    FILL LINE 20mm =85ml

  • MOD8140 Ice Pop Mold
    CAPACITY MAX =123ml
    FILL LINE 6mm =118ml
    FILL LINE 20mm =94ml

  • MOD8174 Ice Pop Mold
    CAPACITY MAX =134ml
    FILL LINE 6mm =126ml
    FILL LINE 20mm =110ml

  • MOD8224 Ice Pop Mold
    CAPACITY MAX =105ml
    FILL LINE 6mm =98ml
    FILL LINE 20mm =83ml

  • MOD8225 Ice Pop Mold
    CAPACITY MAX =80ml
    FILL LINE 6mm =74ml
    FILL LINE 20mm =60ml

  • MOD8234 Ice Pop Mold
    CAPACITY MAX =100ml
    FILL LINE 6mm =95.5ml
    FILL LINE 20mm =78ml

  • MOD8238 Ice Pop Mold
    CAPACITY MAX =105ml
    FILL LINE 6mm =99ml
    FILL LINE 20mm =84ml

  • MOD8350 Ice Pop Mold
    CAPACITY MAX =84ml
    FILL LINE 6mm =78ml
    FILL LINE 20mm =67ml

  • MOD8366 Ice Pop Mold
    CAPACITY MAX =83ml
    FILL LINE 6mm =77ml
    FILL LINE 20mm =62ml

  • MOD8382 Ice Pop Mold
    CAPACITY MAX =59ml
    FILL LINE 6mm =54ml
    FILL LINE 20mm =43ml

  • MOD8441 Ice Pop Mold
    CAPACITY MAX =60ml
    FILL LINE 6mm =57ml
    FILL LINE 20mm =49ml

  • MOD8457 Ice Pop Mold
    CAPACITY MAX =43ml
    FILL LINE 6mm =39ml
    FILL LINE 20mm =29ml

  • MOD8458 Ice Pop Mold
    CAPACITY MAX =75ml
    FILL LINE 6mm =66ml
    FILL LINE 20mm =50ml

  • MOD8459 Ice Pop Mold
    CAPACITY MAX =73ml
    FILL LINE 6mm =67ml
    FILL LINE 20mm =54ml

  • MOD8460 Ice Pop Mold
    CAPACITY MAX =50ml
    FILL LINE 6mm =46ml
    FILL LINE 20mm =38ml

  • MOD8461 Ice Pop Mold
    CAPACITY MAX =75ml
    FILL LINE 6mm =66ml
    FILL LINE 20mm =50ml

  • MOD8462 Ice Pop Mold
    CAPACITY MAX =65ml
    FILL LINE 6mm =60ml
    FILL LINE 20mm =50ml

  • MOD8463 Ice Pop Mold
    CAPACITY MAX =87ml
    FILL LINE 6mm =75ml
    FILL LINE 20mm =53ml

  • MOD8464 Ice Pop Mold
    CAPACITY MAX =60ml
    FILL LINE 6mm =52ml
    FILL LINE 20mm =42ml

  • MOD8465 Ice Pop Mold
    CAPACITY MAX =72ml
    FILL LINE 6mm =67ml
    FILL LINE 20mm =54ml

  • MOD8466 Ice Pop Mold
    CAPACITY MAX =107ml
    FILL LINE 6mm =97ml
    FILL LINE 20mm =73ml

  • MOD8467 Ice Pop Mold
    CAPACITY MAX =97ml
    FILL LINE 6mm =91ml
    FILL LINE 20mm =79ml

  • MOD8468 Ice Pop Mold
    CAPACITY MAX =63ml
    FILL LINE 6mm =58ml
    FILL LINE 20mm =46ml

  • MOD8469 Ice Pop Mold
    CAPACITY MAX =80ml
    FILL LINE 6mm =75ml
    FILL LINE 20mm =64ml

  • MOD8470 Ice Pop Mold
    CAPACITY MAX =58ml
    FILL LINE 6mm =52ml
    FILL LINE 20mm =43ml

  • MOD8471 Ice Pop Mold
    CAPACITY MAX =66ml
    FILL LINE 6mm =62ml
    FILL LINE 20mm =50ml

  • MOD8472 Ice Pop Mold
    CAPACITY MAX =80ml
    FILL LINE 6mm =75ml
    FILL LINE 20mm =60ml

  • MOD8473 Ice Pop Mold
    CAPACITY MAX =74ml
    FILL LINE 6mm =68ml
    FILL LINE 20mm =55ml

  • MOD8474 Ice Pop Mold
    CAPACITY MAX =79ml
    FILL LINE 6mm =72ml
    FILL LINE 20mm =55ml

  • MOD8475 Ice Pop Mold
    CAPACITY MAX =100ml
    FILL LINE 6mm =91ml
    FILL LINE 20mm =71ml

  • MOD8476 Ice Pop Mold
    CAPACITY MAX =125ml
    FILL LINE 6mm =115ml
    FILL LINE 20mm =94ml

  • MOD8477 Ice Pop Mold
    CAPACITY MAX =130ml
    FILL LINE 6mm =120ml
    FILL LINE 20mm =96ml

  • MOD8478 Ice Pop Mold
    CAPACITY MAX =90ml
    FILL LINE 6mm =84ml
    FILL LINE 20mm =67ml

  • MOD8479 Ice Pop Mold
    CAPACITY MAX =83ml
    FILL LINE 6mm =77ml
    FILL LINE 20mm =60ml

  • MOD8480 Ice Pop Mold
    CAPACITY MAX =42ml
    FILL LINE 6mm =37ml
    FILL LINE 20mm =29ml

  • MOD8481 Ice Pop Mold
    CAPACITY MAX =85ml
    FILL LINE 6mm =75ml
    FILL LINE 20mm =55ml

  • MOD8483 Ice Pop Mold
    CAPACITY MAX =105ml
    FILL LINE 6mm =101ml
    FILL LINE 20mm =81ml

  • MOD8484 Ice Pop Mold
    CAPACITY MAX =100ml
    FILL LINE 6mm =96ml
    FILL LINE 20mm =79ml

  • MOD8485 Ice Pop Mold
    CAPACITY MAX =80ml
    FILL LINE 6mm =77ml
    FILL LINE 20mm =65ml

  • MOD8486 Ice Pop Mold
    CAPACITY MAX =76ml
    FILL LINE 6mm =73ml
    FILL LINE 20mm =60ml

  • MOD8487 Ice Pop Mold
    CAPACITY MAX =98ml
    FILL LINE 6mm =91ml
    FILL LINE 20mm =78ml

  • MOD8488 Ice Pop Mold
    CAPACITY MAX =123ml
    FILL LINE 6mm =113ml
    FILL LINE 20mm =73ml

  • MOD8489 Ice Pop Mold
    CAPACITY MAX =127ml
    FILL LINE 6mm =118ml
    FILL LINE 20mm =100ml

  • MOD8490 Ice Pop Mold
    CAPACITY MAX =130ml
    FILL LINE 6mm =121ml
    FILL LINE 20mm =97ml

  • MOD8491 Ice Pop Mold
    CAPACITY MAX =102ml
    FILL LINE 6mm =97ml
    FILL LINE 20mm =84ml

  • MOD8492 Ice Pop Mold
    CAPACITY MAX =110ml
    FILL LINE 6mm =103ml
    FILL LINE 20mm =90ml

  • MOD8493 Ice Pop Mold
    CAPACITY MAX =84ml
    FILL LINE 6mm =75ml
    FILL LINE 20mm =58ml

  • MOD8494 Ice Pop Mold
    CAPACITY MAX =74ml
    FILL LINE 6mm =70ml
    FILL LINE 20mm =58ml

  • MOD8495 Ice Pop Mold
    CAPACITY MAX =100ml
    FILL LINE 6mm =94ml
    FILL LINE 20mm =80ml

  • MOD8496 Ice Pop Mold
    CAPACITY MAX =78ml
    FILL LINE 6mm =72ml
    FILL LINE 20mm =59ml

  • MOD8497 Ice Pop Mold
    CAPACITY MAX =72ml
    FILL LINE 6mm =67ml
    FILL LINE 20mm =58ml

  • MOD8498 Ice Pop Mold
    CAPACITY MAX =201ml
    FILL LINE 6mm =187ml
    FILL LINE 20mm =150ml

  • MOD8499 Ice Pop Mold
    CAPACITY MAX =204ml
    FILL LINE 6mm =185ml
    FILL LINE 20mm =143ml

  • MOD8500 Ice Pop Mold
    CAPACITY MAX =157ml
    FILL LINE 6mm =140ml
    FILL LINE 20mm =102ml

  • MOD8501 Ice Pop Mold
    CAPACITY MAX =36ml
    FILL LINE 6mm =33ml
    FILL LINE 20mm =14ml

  • MOD8502 Ice Pop Mold
    CAPACITY MAX =87ml
    FILL LINE 6mm =79ml
    FILL LINE 20mm =60ml

  • MOD8503 Ice Pop Mold
    CAPACITY MAX =81ml
    FILL LINE 6mm =74ml
    FILL LINE 20mm =60ml

  • MOD8504 Ice Pop Mold
    CAPACITY MAX =86ml
    FILL LINE 6mm =64ml
    FILL LINE 20mm =65ml

  • MOD8505 Ice Pop Mold
    CAPACITY MAX =74ml
    FILL LINE 6mm =68ml
    FILL LINE 20mm =55ml

  • MOD8506 Ice Pop Mold
    CAPACITY MAX =84ml
    FILL LINE 6mm =79ml
    FILL LINE 20mm =68ml

  • MOD8507 Ice Pop Mold
    CAPACITY MAX =67ml
    FILL LINE 6mm =64ml
    FILL LINE 20mm =53ml

  • MOD8508 Ice Pop Mold
    CAPACITY MAX =50ml
    FILL LINE 6mm =45ml
    FILL LINE 20mm =33ml

  • MOD8509 Ice Pop Mold
    CAPACITY MAX =88ml
    FILL LINE 6mm =83.5ml
    FILL LINE 20mm =70ml

  • MOD8510 Ice Pop Mold
    CAPACITY MAX =100ml
    FILL LINE 6mm =95ml
    FILL LINE 20mm =78ml

  • MOD8511 Ice Pop Mold
    CAPACITY MAX =83ml
    FILL LINE 6mm =77ml
    FILL LINE 20mm =60ml

  • MOD8512 Ice Pop Mold
    CAPACITY MAX =24ml
    FILL LINE 6mm =20.3ml
    FILL LINE 20mm =12ml

  • MOD8513 Ice Pop Mold
    CAPACITY MAX =100ml
    FILL LINE 6mm =94ml
    FILL LINE 20mm =79ml

  • MOD8514 Ice Pop Mold
    CAPACITY MAX =203ml
    FILL LINE 6mm =184ml
    FILL LINE 20mm =137ml

  • MOD8515 Ice Pop Mold
    CAPACITY MAX =108ml
    FILL LINE 6mm =101ml
    FILL LINE 20mm =86ml

  • MOD8516 Ice Pop Mold
    CAPACITY MAX =80ml
    FILL LINE 6mm =75ml
    FILL LINE 20mm =65ml

  • MOD8517 Ice Pop Mold
    CAPACITY MAX =91ml
    FILL LINE 6mm =90ml
    FILL LINE 20mm =70ml

  • MOD8518 Ice Pop Mold
    CAPACITY MAX =80ml
    FILL LINE 6mm =79ml
    FILL LINE 20mm =65ml

  • MOD8519 Ice Pop Mold
    CAPACITY MAX =80ml
    FILL LINE 6mm =74ml
    FILL LINE 20mm =65ml

  • MOD8520 Ice Pop Mold
    CAPACITY MAX =72ml
    FILL LINE 6mm =64ml
    FILL LINE 20mm =45ml

  • MOD8521 Ice Pop Mold
    CAPACITY MAX =77ml
    FILL LINE 6mm =71ml
    FILL LINE 20mm =61ml

  • MOD8522 Ice Pop Mold
    CAPACITY MAX =75ml
    FILL LINE 6mm =70ml
    FILL LINE 20mm =61ml

  • MOD8523 Ice Pop Mold
    CAPACITY MAX =83ml
    FILL LINE 6mm =78ml
    FILL LINE 20mm =65ml

  • MOD8524 Ice Pop Mold
    CAPACITY MAX =59ml
    FILL LINE 6mm =54ml
    FILL LINE 20mm =48ml

  • MOD8525 Ice Pop Mold
    CAPACITY MAX =113ml
    FILL LINE 6mm =107ml
    FILL LINE 20mm =90ml

  • MOD8526 Ice Pop Mold
    CAPACITY MAX =101.5ml
    FILL LINE 6mm =97.5ml
    FILL LINE 20mm =78ml

  • MOD8527 Ice Pop Mold
    CAPACITY MAX =111ml
    FILL LINE 6mm =105ml
    FILL LINE 20mm =89ml

  • MOD8528 Ice Pop Mold
    CAPACITY MAX =159ml
    FILL LINE 6mm =148ml
    FILL LINE 20mm =135ml

  • MOD8531 Ice Pop Mold
    CAPACITY MAX =74ml
    FILL LINE 6mm =67ml
    FILL LINE 20mm =55ml

  • MOD8533 Ice Pop Mold
    CAPACITY MAX =218ml
    FILL LINE 6mm =197ml
    FILL LINE 20mm =165ml

Remarks:
Fill line indicates the distance from the top of the mold cup to water line. The capacity tolerance of all mold cups is ±2cc.
